Product Description
Details:
- Sensor: 3.1M/Aptina(C)
- Sensor Size(mm): 1/2.5“ (5.73x4.3)
- Pixel Size(μm): 2.8x2.8
- FPS: 30@2048x1536, 30@1024x768
- Binning: 1x1 1x1
- Exposure: 0.1-1000 ms
- USB Port: USB2.0 High-speed Port
Features:
- Standard C-Mount camera with OnSemi CMOS sensor;
- With hardware resolution 3.1MP;
- USB2.0 interface ensuring high speed data transmission;
- Integrated with large capacity memory chip ensures data synchronous transmission, low latency, high frame rate and stability;
- Compatible with Microsoft USB Video Class protocol and support the third-party software development;
- Built in Ultra-fine hardware ISP engine ensures high color restoration;
(1) Support automatic/manual exposure switching, accurate exposure time control, and real-time adjustment of exposure target area;
(2) Support automatic/manual/ROI white balance;
(3) Support color adjustment/color mode selection/image flipping;
(4) Support histogram adjust/flat field correction/dark field correction/video ROI;
- High performance MJPEG compression algorithm, combined with the unique decoding method of image restoration algorithm ensure highest frame rate of USB2.0 camera in the industry;
- Comply with CE and FCC agreements;
- CNC aluminum alloy housing;
- With advanced video & image processing application ImageView;
- Providing Windows/Linux/Mac OS multiple platforms SDK;
- Very competitive pricing.
Packing information:
- Gift box L:15cm W:15cm H:10cm (0.5~0.55Kg/ box)
- BUC1D-310C USB2.0 C-mount CMOS camera
- High-speed USB2.0 A male to B male gold-plated connectors cable /2.0m
- USB flash disk (Driver & utilities software)
