Product Description
HDMI Camera:
- Image Sensor: CMOS, Aptina MT9P031
- Sensor Size: 1/2.5"
- Video Resolution: 1920 × 1080
- Image Resolution: 2592 × 1944
- Frame Rate: 1920 × 1080 15fps via USB2.0, 1920 × 1080 15fps via HDMI
- Data Record: SD Card (4G)
- Video Record: 1080p 15fps @ SD Card, 1080p 15fps @ PC
- Scan Mode: Progressive
- Electronic Shutter: Electronic Rolling Shutter
- A/D conversion: 8 bit
- Color Depth: 24bit
- Sensitivity: 510mV
- Dynamic Range: 60dB
- S/N ratio: 40.5dB
- Exposure time: 0.001 sec ~ 10.0 sec
- Exposure: Auto/Manual
- White balance: Auto
- Settings: Gain, Gamma, Saturation, Contrast
- Built- in software: Cloud 1.0 version
- PC software: Capture2.0
- Output model 1: USB2.0
- Output model 2: HDMI
- System Compatible: Windows XP/Vista/Win 7/Win 8/10(32 and 64-bit ), MAC OSX
- Optical port: C- Mount
- Power Supply DC 12V /2A
- Operational Temperature: 0-60°C
- Humidity: 45%-85%
- Storage Temperature: -20-70°C
Retina Screen:
- Screen Size: 11.6 inch
- Aspect Ratio: 16:9
- Display Resolution: 1920 × 1080
- Display Type: IPS-PRO
- Brightness: 320cd/m2
- Static Contrast Ratio: 1000:1
- Input: 1*HDMI PORT
- Power Supply: DC 12V /2A External Adapter
- Dimension: 282mm×180.5mm×15.3mm
- Net Weight: 600g
Features:
- Control camera with mouse from USB port, no shaking.
- 11.6” retina HD LCD Screen, high definition and high quality color reproduction.
- 5.0MP still image capture and 1080P Video Recording.
- Save image and video to SD card.
- Also can be connected to PC and take picture, take video, do measurement and analyze images.
- Standard C-mount Interface for different microscopes.
Application:
- Biological Teaching Digital Imaging
- Live Cell Imaging
- Surgical Microscopic Imaging
- Pathology
- Cytology
- Defect Analysis
- Semiconductor Inspection
- Navigation for Processed Imaging
- Industrial Optical HD Digital Imaging
- Astronomical Observation
