1. Feature
- CMOS Camera with a 10.1-inch LCD touch screen, Mini HDMI output port and dual USB-C ports. The USB ports of BLC-240A are for USB storage devices and mouse. For BLC-240B, the USB1 and USB2 interfaces can be connected to USB storage devices and mouse, while USB2 can also be connected to computers for image data transfer.
- Built-in software supports high-speed image acquisition and preview, strong light suppression, wide dynamic range, realistic color reproduction, and clear image. It has multiple ISP adjustment functions, supporting photography, video recording and preview, with rich measurement functions.
2. Specification
|
Screen |
10.1 inch IPS TFT-LCD |
|
Screen Resolution |
1920*1200 |
|
Screen Color |
16.7M, 72% NTSC |
|
Luminance |
300cd/m2 |
|
Contrast Ratio |
800:1 |
|
Viewing Angle |
89/89/89/89 |
|
Processor |
ARM-A55 64-bit Quad Core 1.5GHz |
|
Running Memory |
16 GB |
|
Built-in Storage |
256 GB |
|
Network |
Support 5G and 2.4G Wifi, independent sigle antenna |
|
Sensor |
SONY IMX307 (C) |
|
Sensor Size |
1/2.8” |
|
Resolution |
1920*1080 2MP |
|
Pixel |
2.9μm*2.9μm |
|
HDMI Interface |
HDMI 1.4 1920*1080@60fps (Mini) |
|
Dual USB-C Interface |
Connect to USB mouse, USB disk |
|
SD Card Slot |
Supporting |
|
Power Button |
Short press to turn on, long press to turn off |
|
Photo Button |
Supporting |
|
Power Supply |
DC 12V/ 2A |
|
Operating System |
Android 12 |
|
Optional Software |
TScopePadView |
|
Auxiliary functions |
Exposure and gain adjustment, white balance, color adjustment, automatic sharpening, automatic denoising, light source frequency, flipping, etc. |
|
Measurement Function |
Straight line length, broken line length, distance between parallel line, point to line distance, radius circle, three-point circle, concentric circle, center distance, polygon, rectangle, three-point angle, measurement data export, etc. |
|
Image |
2M (1920*1080) JPEG |
|
Vedio |
2M (1920*1080) MP4 30fps |
|
Language |
Chinese/ Tradional Chinese/ Russian/ English/ German/ French/ Japanese/ Itlian |
